SITECO Connect 21
SITECO Connect 21 is the comprehensive indoor control solution for all control requirements. It offers high functionality and is still easy to use. SITECO Connect 21 combines the topics of sustainability, productivity, flexibility and well-being and is aimed at the areas of application in industry, retail and offices.
SITECO Connect solution kit
![](/asset/emea_en/en/PNG/1007404/impression-657-1.png)
SITECO Connect 21 O
Intro to ProductfamilyData
Article lighting management components; repeater
Control DALI; DALI 2
Specials
Controller available as DIN rail PC
Future-proof: through open and standardized DALI2 interface
Easy commissioning: all function via commissioning software
Manual intervention: possible at any time by users
Future-proofing and flexibility: through individual addressing and grouping of luminaires and sensors
Cost efficiency: accelerating payback through sensors (daylight and motion)
SITECO HCLlive: light influences our body visually, emotionally and biologically. It sets the pace for our internal clock
Intelligence: intelligent control of luminaires depending on partition walls (e.g. sports halls, meeting rooms, etc.)
Configuration & Datasheets
With SITECO Connect 21O, the complete control intelligence is combined in one device
Incl. 2 DALI lines
Per DALI line max. 250mA power supply
Per DALI line max. 64 ECG and 64 sensor addresses
DALI2 certified according to part 101, 103, 303 and 304
Max. 8 controllers can be networked
Incl. 2 DALI lines
Per DALI line max. 250mA power supply
Per DALI line max. 64 ECG and 64 sensor addresses
DALI2 certified according to part 101, 103, 303 and 304
Max. 8 controllers can be networked
Results
controller
Order No.: 5LZ904712A GTIN (EAN): 4058352548448
Family | Article | Equipment | Colour | Installation location | Wt. (kg) |
---|---|---|---|---|---|
SITECO Connect 21-O | controller | master | grey | in an electrical distributor | 0.2 |
repeater
Order No.: 5LZ904001 GTIN (EAN): 4008321301093
Family | Article | Equipment | Colour | Installation location | Wt. (kg) |
---|---|---|---|---|---|
DALI | repeater | master | grey | in an electrical distributor | 0.2 |
repeater
Order No.: 5LZ904002 GTIN (EAN): 4008321292599
Family | Article | Equipment | Colour | Installation location | Wt. (kg) |
---|---|---|---|---|---|
DALI | repeater | master | grey | in the luminaire | 0.1 |
controller
Order No.: 5LZ904712AGTIN (EAN): 4058352548448
Family | SITECO Connect 21-O |
---|---|
Article | controller |
Equipment | master |
Colour | grey |
Installation location | in an electrical distributor |
Wt. (kg) | 0.2 |
repeater
Order No.: 5LZ904001GTIN (EAN): 4008321301093
Family | DALI |
---|---|
Article | repeater |
Equipment | master |
Colour | grey |
Installation location | in an electrical distributor |
Wt. (kg) | 0.2 |
repeater
Order No.: 5LZ904002GTIN (EAN): 4008321292599
Family | DALI |
---|---|
Article | repeater |
Equipment | master |
Colour | grey |
Installation location | in the luminaire |
Wt. (kg) | 0.1 |
