Silica® 21
The Silica® 21 offers maximum flexibility in use and is suitable for all mounting situations thanks to its modular design. It is the ideal basis for a smart office through flexible expansion with intelligent sensors, for example for room data acquisition with an open interface. As a sustainable luminaire thanks to easily exchangeable components, the Silica® 21 is the perfect solution for individual projects thanks to the modular principle.
Our open solution: modular, networked, adaptable and open in design
sensor modules with DALI-2 interface
Intro product family
Key data
Equipment slave
Article sensor PC3; sensor PR3
Special features
Wired solution with DALI-2 interface consisting of sensor modules, operating interfaces and accessories
Please select the controller that meets your requirements under "mandatory accessories" and order separately
Open DALI-2 certified interface according to parts 101, 103, 303 and 304 provide full flexibility
Standard luminaires are integrated into the system using modular sensor modules
Sensor module PR3-S with integrated multi-sensor function. Integrated light, presence and motion sensor for single workstations
Sensor module PC3-S with integrated multi-sensor function. Integrated light, presence and motion sensor for e.g. group offices and meeting rooms
Basic energy-saving functions such as presence and motion detection, daylight control and fully automatic operation reduce energy costs and CO2 consumption
Suitable for single and continuous row arrangement
Configuration & data sheets
- DALI-2 certified according to parts 101,103,303,304
- DALI current sensor PR3-S I= 6mA
- DALI current sensor PC3-S I= 12mA
- light sensor opening angle α/2 = 45°
- presence and movement sensors: see range diagram
- suitable for single and continuous row arrangement
Results
Silica® 21, sensor PR3, traffic white (RAL 9016)
Order No.: 59MX2BD000WA GTIN (EAN): 4058352602782
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PR3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PR3, jet black (RAL 9005)
Order No.: 59MX2BD000BA GTIN (EAN): 4058352605950
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PR3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PR3, metallic grey (RAL 9006)
Order No.: 59MX2BD000SA GTIN (EAN): 4058352605967
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PR3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PC3, traffic white (RAL 9016)
Order No.: 59MX2CD000WA GTIN (EAN): 4058352605998
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PC3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PC3, jet black (RAL 9005)
Order No.: 59MX2CD000BA GTIN (EAN): 4058352605974
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PC3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PC3, metallic grey (RAL 9006)
Order No.: 59MX2CD000SA GTIN (EAN): 4058352605981
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PC3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PR3, traffic white (RAL 9016)
Order No.: 59MX2BD100WA GTIN (EAN): 4058352760352
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PR3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PR3, jet black (RAL 9005)
Order No.: 59MX2BD100BA GTIN (EAN): 4058352760314
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PR3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PR3, metallic grey (RAL 9006)
Order No.: 59MX2BD100SA GTIN (EAN): 4058352760338
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PR3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PC3, traffic white (RAL 9016)
Order No.: 59MX2CD100WA GTIN (EAN): 4058352760475
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PC3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PC3, jet black (RAL 9005)
Order No.: 59MX2CD100BA GTIN (EAN): 4058352760444
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PC3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PC3, metallic grey (RAL 9006)
Order No.: 59MX2CD100SA GTIN (EAN): 4058352760451
| Article | Application area | Supplement | System family | Mounting height | Price (EUR) |
|---|---|---|---|---|---|
| sensor PC3 | office | for surface-mounted luminaires, for pendant luminaires | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office | 2.5..5m | 202.00 |
Silica® 21, sensor PR3, traffic white (RAL 9016)
Order No.: 59MX2BD000WAGTIN (EAN): 4058352602782
| Article | sensor PR3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PR3, jet black (RAL 9005)
Order No.: 59MX2BD000BAGTIN (EAN): 4058352605950
| Article | sensor PR3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PR3, metallic grey (RAL 9006)
Order No.: 59MX2BD000SAGTIN (EAN): 4058352605967
| Article | sensor PR3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PC3, traffic white (RAL 9016)
Order No.: 59MX2CD000WAGTIN (EAN): 4058352605998
| Article | sensor PC3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PC3, jet black (RAL 9005)
Order No.: 59MX2CD000BAGTIN (EAN): 4058352605974
| Article | sensor PC3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PC3, metallic grey (RAL 9006)
Order No.: 59MX2CD000SAGTIN (EAN): 4058352605981
| Article | sensor PC3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PR3, traffic white (RAL 9016)
Order No.: 59MX2BD100WAGTIN (EAN): 4058352760352
| Article | sensor PR3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PR3, jet black (RAL 9005)
Order No.: 59MX2BD100BAGTIN (EAN): 4058352760314
| Article | sensor PR3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PR3, metallic grey (RAL 9006)
Order No.: 59MX2BD100SAGTIN (EAN): 4058352760338
| Article | sensor PR3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PC3, traffic white (RAL 9016)
Order No.: 59MX2CD100WAGTIN (EAN): 4058352760475
| Article | sensor PC3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PC3, jet black (RAL 9005)
Order No.: 59MX2CD100BAGTIN (EAN): 4058352760444
| Article | sensor PC3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Silica® 21, sensor PC3, metallic grey (RAL 9006)
Order No.: 59MX2CD100SAGTIN (EAN): 4058352760451
| Article | sensor PC3 |
|---|---|
| Application area | office |
| Supplement | for surface-mounted luminaires, for pendant luminaires |
| System family | Siteco Connect 11, SITECO Connect 21B, SITECO Connect 21H, SITECO Connect 31 Office |
| Mounting height | 2.5..5m |
| Price (EUR) | 202.00 |
Mandatory accessories
| Order No.: 5LZ904712AGTIN (EAN): 4058352548448 | Show all details |
| Order No.: 5LZ930100GTIN (EAN): 4058352385906 | Show all details |
| Order No.: 5LZ930101GTIN (EAN): 4058352385913 | Show all details |
| Order No.: 5LZ930102GTIN (EAN): 4058352385920 | Show all details |
| Order No.: 5LZ930103GTIN (EAN): 4058352385937 | Show all details |
| Order No.: 5LZ904731AGTIN (EAN): 4058352580318 | Show all details |
| Order No.: 5LZ925601GTIN (EAN): 4058352362020 | Show all details |
| Order No.: 5LZ905950GTIN (EAN): 4058352668863 | Show all details |
| Order No.: 5LZ935100AGTIN (EAN): 4058352838051 | Show all details |
| Order No.: 5LZ935400AGTIN (EAN): 4058352838136 | Show all details |
