SITECO Connect 21

ProducttypesConfiguration & Datasheets

SITECO Connect 21 is the comprehensive indoor control solution for all control requirements. It offers high functionality and is still easy to use. SITECO Connect 21 combines the topics of sustainability, productivity, flexibility and well-being and is aimed at the areas of application in industry, retail and offices.

SITECO Connect solution kit

Producttypes

SITECO Connect 21 B

SITECO Connect 21 O

SITECO Connect 21 O (DALI1)

SITECO Connect 21 B

Intro to Productfamily

Data

Descripción unidad de control
Control DALI 2

Specials

Controller available as DIN rail PC
Future-proof: through open and standardized DALI2 interface
Easy commissioning: all function via commissioning software
Access: different user rights and roles provide functional security
Manual intervention: possible at any time by users
Future-proofing and flexibility: through individual addressing and grouping of luminaires and sensors
Cost efficiency: accelerating payback through sensors (daylight and motion)
Proactive: automatic control of lighting through intelligent time schedules
SITECO HCLlive: light influences our body visually, emotionally and biologically. It sets the pace for our internal clock
Everything in view: web visualization of the entire solution (license already included)
Status of the lighting system: visualization of sensor and luminaire faults
Energy consumption: visualization of the energy consumption of the lighting system possible
Intelligence: intelligent control of luminaires depending on partition walls (e.g. sports halls, meeting rooms, etc.)
Remote maintenance: commissioning or analysis of the lighting system can also be carried out remotely if required

Configuration & Datasheets

  • with SITECO Connect 21B, the complete control intelligence is combined in one device
  • incl. controller, bus power supply, circuit breaker and software license
  • incl. 2 DALI lines
  • per DALI line max. 250mA power supply
  • per DALI line max. 64 ECG and 64 sensor addresses
  • DALI2 certified according to part 101, 103, 303 and 304
  • can be expanded to max. 4 DALI lines using modular DALI2 terminals

Results

controlador

Referencia: 5LZ960100 GTIN (EAN): 4058352651612
FamiliaDescripciónEquipamientoControlLugar de montajePeso (kg)
SITECO Connect 21BcontroladormaestroDALI 2en una distribución eléctrica0,2
Show details
EspecificaciónHoja de datos (PDF, completo)All Downloads

controlador

Referencia: 5LZ960100GTIN (EAN): 4058352651612

FamiliaSITECO Connect 21B
Descripcióncontrolador
Equipamientomaestro
ControlDALI 2
Lugar de montajeen una distribución eléctrica
Peso (kg)0,2
Show details

Optional accessory

Descripciónborne DALI-2, DALI 2, control centralUE1 unidadPeso (kg)0,1Referencia: 5LZ971005GTIN (EAN): 4058352797723Show details
DescripciónInterface S, en el carril de soporte Licross®UE1 unidadPeso (kg)0,8Referencia: 56TL1FCSAGTIN (EAN): 4058352373880Show details
DescripciónInterface S, en el carril de soporte Modario®UE1 unidadPeso (kg)0,4Referencia: 5TR305FCSAGTIN (EAN): 4058352635711Show details
Descripciónmódulo de zócalo, esclava, blancoUE1 unidadPeso (kg)0,3Referencia: 59HL94002GTIN (EAN): 4058352379349Show details
DescripciónExternal Interface S, montaje superficial en el techoUE1 unidadPeso (kg)0,1Referencia: 59US1FCSAGTIN (EAN): 4058352361948Show details
Descripciónmódulo de sensor PC3-S, esclava, blanco, h= 2,5..5mUE1 unidadPeso (kg)0,3Referencia: 56TL1MDSPC3AGTIN (EAN): 4058352407615Show details
Descripciónmódulo de sensor PC3-S, esclava, negro, h= 2,5..5mUE1 unidadPeso (kg)0,3Referencia: 56TL3MDSPC3AGTIN (EAN): 4058352407639Show details
Descripciónmódulo de sensor PC3-S, esclava, plateado, h= 2,5..5mUE1 unidadPeso (kg)0,3Referencia: 56TL6MDSPC3AGTIN (EAN): 4058352407653Show details
Descripciónmódulo de sensor PS2-S, h= 2,5..10m, en el carril de soporte Licross®UE1 unidadPeso (kg)0,7Referencia: 56TL1MDSPS2AGTIN (EAN): 4058352400685Show details
Descripciónsensor PE1, h= 5..14m, empotrado en el carril de soporte Licross®UE1 unidadPeso (kg)0,6Referencia: 56TN1SDSPE1BGTIN (EAN): 4058352596326Show details
Descripcióndetector de presencia, sensor PE1, esclava, DALI 2, montaje superficialUE1 unidadPeso (kg)0,4Referencia: 59HL94003GTIN (EAN): 4058352641941Show details
Descripciónmultisensor PS2, h= 2,5..10m, empotrado en el techoUE1 unidadPeso (kg)0,2Referencia: 5LZ925601GTIN (EAN): 4058352362020Show details
Descripcióninterfaz de pulsador, esclava, DALI 2UE1 unidadPeso (kg)0,1Referencia: 5LZ911731AGTIN (EAN): 4058352692899Show details
