Canna 200, luminaire head, PL64, metallic grey (DB 703)

Close
Ordercode: 5BS0021E3B09P
Remember productRemember product

Article luminaire head
Product name Canna 200
Lamp LED
Rated luminous flux 3310lm
Luminous efficacy 110lm/W
Colour temperature 3000K
Colour rendering CRI > 80
Pnom begin service life 30
Pnom end service life 37
Service life 100000h (L90/B10) at AT = 25°C
Protection rating IP67
Weight 10.3kg

Canna 200, luminaire head, LED module, primary light control with lens, of PMMA, primary optical cover: cover, of PMMA, transparent, light distribution: PL64, primary light characteristic: asymmetric, LED, High Power LED, rated luminous flux: 3.310lm, luminous efficacy: 110lm/W, light colour: 830, colour temperature: 3000K, mains connection: 220..240V, AC, 50/60Hz, start of lifetime: 30W, end of service life: 37W, luminaire housing, cylindrical, of aluminium, coated, metallic grey (DB 703), length: 900mm, diameter: 200mm, LED module, equipment: Power, protection rating (complete): IP67, insulation class (complete): insulation class II (safety insulation), certification: CE, ENEC, packaging unit: 1 piece

Downloads

Technical product information
Data for application programs

Product details

Key data

Product type luminaire head
Product name Canna 200
Order No. 5BS0021E3B09P

Lighting technology

Light control lens of PMMA
Cover cover, transparent
Light distribution PL64
Beam angle narrow distribution
Symmetry asymmetric distribution

Lamps

Lamps with High Power LED, LED
Rated luminous flux 3310lm
Luminous efficacy 110lm/W
Colour temperature 3000K
Colour rendering index CRI > 80
Light colour 830
SDCM (Standard Deviation of Colour Matching) MacAdam ≤ 3 SDCM (initial)
Rated input power begin service life 30
Rated input power end service life 37

Operating device

Control DALI 2

Certificates, Standards

Protection rating IP67
Insulation class insulation class II (safety insulation)
Certification, designation CE, ENEC

Material, Colour

luminaire housing aluminium, coated, metallic grey (DB 703), cylindrical
Colour specification metallic grey (DB 703)
Cover cover of PMMA

Electrical connection

Nominal voltage 220..240V, 50/60Hz, AC
Surge voltage resistance surge voltage resistance: 10kV (common mode); 6kV (differential mode)

Dimensions, Weight

Length 900mm
Diameter 200mm
Weight 10.3kg

Service life

Rated service life 100000h (L90/B10) at AT = 25°C

Product type
luminaire head

Product name
Canna 200

Order No.
5BS0021E3B09P

Light control
lens of PMMA

Cover
cover, transparent

Light distribution
PL64

Beam angle
narrow distribution

Symmetry
asymmetric distribution

Lamps
with High Power LED, LED

Rated luminous flux
3310lm

Luminous efficacy
110lm/W

Colour temperature
3000K

Colour rendering index
CRI > 80

Light colour
830

SDCM (Standard Deviation of Colour Matching)
MacAdam ≤ 3 SDCM (initial)

Rated input power begin service life
30

Rated input power end service life
37

Control
DALI 2

Protection rating
IP67

Insulation class
insulation class II (safety insulation)

Certification, designation
CE, ENEC

luminaire housing
aluminium, coated, metallic grey (DB 703), cylindrical

Colour specification
metallic grey (DB 703)

Cover
cover of PMMA

Nominal voltage
220..240V, 50/60Hz, AC

Surge voltage resistance
surge voltage resistance: 10kV (common mode); 6kV (differential mode)

Length
900mm

Diameter
200mm

Weight
10.3kg

Rated service life
100000h (L90/B10) at AT = 25°C
